Product Description
Alrightpower offer 60V battery charger varies from 100W to 3600W. With advanced Single-chip microcomputer (MCU) four stage smart charging technology, our battery charger can use different charging modes according to different types of battery and can trace the charging process correctly. Alrightpower battery charger main applications are electric bicycles, tricycles, scooters, power tools forklift, ground washer, electric motorcycle, electric motorcycle, golf cart, sightseeing car, cleaning car, low speed car and other kinds of devices need charge the battery.
Features
- Typical output: 60V 60A battery charger
- Fully auto 4 stages charging process by MCU controller
- 4 LED indicate the battery capacity from 25%~100%
- Worldwide AC input 100V-240V
- Charging stage: Small current pr-charge; constant current charging; Constant voltage charging
Specifications
The Specification of 60V 60A Battery charger |
|||||
| Charger Model | AC input Voltage | Battery Voltage | Max Voltage (V) | Max Current (A) | |
| AP-PF3600CH02921200 | 220 | 24 | 29.2 | 120 | |
| AP-PF3600CH04201000 | 220 | 36 | 42 | 100 | |
| AP-PF3600CH05460700 | 220 | 48 | 54.6 | 70 | |
| AP-PF3600CH07140600 | 220 | 60 | 71.4 | 60 | |
| AP-PF3600CH08400500 | 220 | 72 | 84 | 50 | |
| AP-PF3600CH02401200 | 220 | 24 | 29.4 | 120 | |
| AP-PF3600CH03601000 | 220 | 36 | 44.1 | 100 | |
| AP-PF3600CH04800700 | 220 | 48 | 58.8 | 70 | |
| AP-PF3600CH06000600 | 220 | 60 | 73.5 | 60 | |
| AP-PF3600CH07200500 | 220 | 72 | 88.2 | 50 | |
| INPUT | AC Input Voltage Range | 100V ~ 240V | |||
| AC input Frequency | 45~65HZ | ||||
| AC Power Factor Correction | ≥0.98 | ||||
| OUTPUT | Output Voltage Range | 24V～90V | |||
| Output Power Range | 120A (Max) | ||||
| VIBRATION | 10～50HZ 2G 10 minutes, X, Y, Z /60 minutes | ||||
| DIMENSIONS (mm) | (L)315х(W)180х(H)90 | ||||
| Protections | Over current protection, Over Voltage Protection, Short- circuit Protection Reverse Connection Protection, Battery open-circuit protection | ||||
| CERTIFICATIONS | Safety Approval: CE ROHS | ||||
| PACKING DETAILS | 9kg/pcs
2pcs/Carton Carton size: 615*520*235mm |
||||
FAQs
1. Is your Battery Charger are safe to use?
Our battery charger meet the requirements of safety approvals and products itself with all kinds of protections such as over voltage protection, over current protection. Polarity error protection, Over power protection.
2. What is your warranty policy for Battery charger?
Our battery charger warranty is 1 years. High quality is one of our advantages which makes our power adapter sells well around the world.
3. What kinds of Battery Charger your factory can offer?
According to Battery Type, we can offer lithium battery chargers for LiFePO4, Li-ion, Li-polymer batteries and Lead-Acid Battery chargers for SLA, silicon, AGM batteries.
According to applications, we can offer electric bicycles Battery Charger, Skateboard Battery Charger, Motorcycle Battery Charger, Lawnmower Battery Charger, Golf-cart Battery Charger and forklift battery charger.
4. What is your the charging Process of lithium battery chargers?
Stage 1: The floating charging phase (Trickle charge)
Stage 2: The constant current charging phase. The charging current remains constant, the charging power increases rapidly. (CC MODE)
Stage 3: The constant Voltage charging phase (CV MODE)
Stage 4: Cut off charging
